Production Capabilities
▸ Capacity: 80 – 300 kg/h
▸ Line speed: up to 16 m/min
▸ Layer capability: up to 2 layers
▸ Rigid material processing structure
System Structure
▸ Extruder diameter: Ø65 – Ø110 mm
▸ L/D configurations: 24 / 28 / 32
▸ Compact extruder and co-extrusion architecture
▸ Rear-feeding compatible main die system
▸ Dynamic production infrastructure with synchronized line operation
Material Range
▸ WPC
▸ PVC and custom wood composite materials
Efficiency
▸ Up to 87% energy savings compared to conventional drive systems, verified through optimized motor and heating control design
▸ Energy consumption: 0.18 – 0.22 kW/kg
Automation & Control
▸ Industry 4.0 infrastructure with system integration
▸ Remote monitoring and control
▸ PLC-based multi-access control system
▸ User-friendly HMI interface
▸ PID + SSR control systems
▸ Customized dosing systems based on material structure
