Core Capabilities
▸ Up to 87% energy savings compared to conventional drive systems, verified through optimized motor and heating control design
▸ Compact line structure with optimized space utilization
▸ Multi-layer sheet production capability up to 7 layers
▸ High-precision thickness control with servo / hydraulic adjustment
▸ Automatic thickness stabilization and tolerance correction
▸ Consistent surface quality with advanced calender roll technology
System Architecture
▸ Main extruder: Ø40 – Ø160 mm
▸ L/D ratio: 30
▸ Inclined calender system with synchronized line structure
▸ Independent or integrated operation with extrusion line
▸ Full synchronization between extruder and downstream units
Material Range
▸ PC, PMMA, PS, PET, PETG
▸ PP, PE
Calender & Process Technology
▸ Double-layer special flow calender rolls
▸ ±1°C roll temperature tolerance
▸ Linear guide bearing system
▸ Servo / hydraulic thickness adjustment
▸ Automatic tolerance adjustment system
▸ Layer distribution and edge control
▸ Advanced cooling and surface stabilization
Technical Range
▸ Working width: 300 mm – 2400 mm
▸ Thickness range: 0.07 mm – 18 mm
▸ Multi-layer configurations available
▸ Independent or fully integrated line options
Automation & Control
▸ Industry 4.0 infrastructure with system integration
▸ Remote monitoring and control
▸ PLC-based multi-access control system
▸ User-friendly HMI interface
Safety & Reliability
▸ Personnel protection sensor barriers
▸ Emergency stop systems
▸ CE, UL and CSA compliant
▸ 10-year spare parts and service guarantee
▸ ROI annual range: 50% – 300%
Application Areas
▸ Transparent and colored sheet production (PC, PMMA, PETG)
▸ Office partitions and shower cabins
▸ Advertising panels and display sheets
▸ HMI, TV, laptop and mobile screen sheets
▸ Aviation interior panels and transparent components
▸ Reinforced unbreakable glass alternatives
▸ Automotive interior components
▸ Roof and wall panels
▸ Medical applications (serum and blood bags)
▸ Notebook covers and packaging sheets
▸ Luggage production sheets
