Core Capabilities
▸ Up to 87% energy savings compared to conventional drive systems, verified through optimized motor and heating control design
▸ Compact line design with maximum space efficiency
▸ Multi-layer production capability up to 4 and 7 layers depending on configuration
▸ Advanced UV coating technology up to 30 micron with ±10% tolerance on profile surfaces
▸ Stable production with fully synchronized line structure
▸ High adaptability for technical and standard materials
System Architecture
▸ Main extruder: Ø40 – Ø140 mm
▸ Co-extruders: Ø25 – Ø65 mm
▸ Twin-screw extruder option: Ø65 – Ø110 mm
▸ L/D ratio: 30 (32 / 37 optional)
▸ Twin-screw L/D: 24 / 28 / 32
▸ Co-extruder L/D: 26
▸ Mono, co-extrusion and twin-screw configurations
▸ Fully synchronized operation with all downstream equipment
Material Range
▸ PC, PMMA, POM, ABS, PS
▸ PVC, WPC
▸ PP, PE
▸ TPE, TPV, EVA, TPO
Automation & Control
▸ Industry 4.0 infrastructure with full system integration
▸ Remote monitoring and control
▸ PLC-based multi-access control system
▸ User-friendly HMI interface
▸ PID + SSR control systems
▸ Custom dosing systems based on production needs
Engineering Strength
▸ UV surface coating technology for high-end profile finishing
▸ Precision calibration with heating and cooling systems
▸ Custom-built solutions based on profile geometry
▸ Optimized screw design for technical materials
▸ Stable pressure and temperature control
▸ Full synchronization between extruder and downstream units
Production Versatility
Single line – wide product range:
▸ H profiles, U profiles, click systems
▸ LED lighting and automotive lighting profiles
▸ Roof connection profiles
▸ Highway snow protection barriers
▸ Railway sound barriers
▸ Shelf labeling systems
▸ Energy distribution rails
▸ PVC wall panels, PVC profiles, and furniture components
▸ PVC and WPC profiles
▸ Polystyrene skirting and ventilation parts
▸ Anti-spray truck side profiles (PE / PVC)
▸ Magnet and heat shrink tube production
▸ Custom rigid profiles
Compliance & Reliability
▸ CE, UL, CSA, Atex and Ex-Proof compliant
▸ 10-year spare parts and service guarantee
▸ ROI range: 50% – 300%
