Key Advantages
▸ Full Automation
Automatic coil change, discharge, and optional loading.
▸ Precise Tension Control
Torque-controlled system with adjustable tension percentage.
▸ Continuous Operation
Dual-arm structure for uninterrupted winding.
▸ Smart Control System
IO-supported program with independent motor control.
▸ User Experience & Reliability
User-friendly HMI, Faster ROI & Long-Term Support
Technical Specifications
▸ Winding Type: Dual-arm automatic system
▸ Shaft System: Air shaft / air expanding shafts
▸ Coil Handling: Automatic discharge and optional loading
▸ Coil Change: Automatic coil change system
▸ Cutting System: Automatic length-based cutting
▸ Tension Control: Electronic torque-controlled system
▸ Motor Control: Independent motors with inverter
▸ Tension Adjustment: Percentage-based electronic control
▸ Control System: IO-supported program
▸ Synchronization: Extruder synchronized or standalone operation
▸ Compliance: CE, UL, CSA
Engineering & System Details
▸ Fully automatic system control mode
▸ Stable and uniform winding structure
▸ Independent operation capability
▸ Remote monitoring and control
▸ Multi-zone access and control system
▸ 10-year spare parts availability and service guarantee
Application Areas
▸ Sheet winding processes
▸ PVC, PP, PE, PC sheet production
▸ Soft and rigid sheet applications
▸ Continuous extrusion lines
