Key Advantages
▸ Performance:
High output with stable and continuous production.
▸ Energy Efficiency:
Up to 87% energy savings compared to conventional drive systems, verified through optimized motor and heating control design.
▸ Flexibility:
Processes three different materials simultaneously.
▸ Technology:
Industry 4.0 ready with full system synchronization.
▸ User Experience:
User-friendly HMI with remote control access, Faster ROI & Long-Term Support
Technical Specifications
▸ Capacity: 50 – 1200 kg/h
▸ Main Extruder Diameter: Ø40 – Ø140 mm
▸ Co-Extruder Diameter (1 & 2): Ø25 – Ø65 mm
▸ Main Extruder L/D Ratio: 30
▸ Co-Extruder L/D Ratio: 26
▸ Material Compatibility: TPE, TPV, PVC, EVA, PC, PP, PE and more
▸Prosses Control System: PID with SSR
▸ Standards Compliance: CE, UL, CSA, Atex and Ex-Proof
Engineering & System Details
▸ Compact design for space efficiency
▸ Full system synchronization
▸ Custom dosing systems
▸ Material-specific degassing system
▸ Remote control capability
▸ Multi-access control system
▸ 10-year spare parts and service guarantee
Application Areas
▸ Multi-layer profile extrusion
▸ Technical profiles
▸ Soft and rigid products
▸ Laboratory and R&D use
▸ Co-extrusion applications
