Key Advantages
▸ High Cutting Accuracy
±0.5 mm tolerance with encoder-based measurement.
▸ Wide Working Range
8–2050 mm working width with adjustable cutting length.
▸ Stable Cutting Motion
Servo-driven forward movement with pneumatic cutting action.
▸ Robust Cutting System
Saw-based cutting for clean and controlled operation.
▸ User Experience & Reliability
User-friendly HMI, Faster ROI & Long-Term Support
Technical Specifications
▸ Working Width: 8 mm – 2050 mm
▸ Cutting Length: Adjustable
▸ Cutting Thickness: Variable
▸ Cutting Tolerance: ±0.5 mm
▸ Forward Motion: Servo motor
▸ Cutting Motion: Pneumatic
▸ Cutting System: Saw-based
▸ Measurement: Encoder-based precise length measurement
▸ Synchronization: Extruder synchronized or standalone operation
▸ Compliance: CE, UL, CSA
Engineering & System Details
▸ Linear rail bearing system for smooth cutting motion
▸ Stable and controlled cutting mechanism
▸ Integrated counter system
▸ Independent operation capability
▸ Remote monitoring and control
▸ Multi-zone access and control system
▸ 10-year spare parts availability and service guarantee
Application Areas
▸ Profile and sheet cutting processes
▸ PVC, PP, PE, PC materials
▸ Soft and rigid product cutting
▸ Continuous extrusion lines
