Production Capabilities
▸ Capacity: up to 700 kg/h
▸ Width: 1220 mm – 2050 mm
▸ Thickness: 3 mm – 35 mm
▸ Layer capability: up to 3 layers
▸ Co-extrusion: dual-component structure with UV layer technology
System Structure
▸ Main extruder: Ø60 – Ø130 mm
▸ L/D ratio: 30
▸ Compact extruder and co-extrusion structure
▸ Pneumatic thickness adjustment system
▸ Automatic thickness locking and tolerance stabilization
▸ Fully synchronized line operation with extrusion system
Material Range
▸ PC, PMMA, GPPS
Process & Cooling Technology
▸ Three-axis movement system with motorized or servo-controlled combinations
▸ Stainless steel circulation infrastructure
▸ Stainless vacuum and water pump systems
▸ Jack-supported collectors
▸ Specialized heating and cooling system for polycarbonate processing
▸ Vacuum calibration system with up to 980 mbar suction capacity
▸ Layer edge trimming system
▸ Stable sealing and cooling performance for multiwall structures
Efficiency
▸ Up to 87% energy savings compared to conventional drive systems, verified through optimized motor and heating control design
▸ Energy consumption: approx. 0.20 kW/kg
▸ ROI range: annual 50% – 90%
Automation & Control
▸ Industry 4.0 infrastructure with system integration
▸ Remote monitoring and control
▸ PLC-based multi-access control system
▸ User-friendly HMI interface
Application Areas
▸ Agriculture
▸ Construction
▸ Thermal and acoustic insulation
▸ Defense
▸ Automotive
▸ Advertising
Product Highlights
▸ Multiwall polycarbonate sheet production
▸ Single-wall PC sheet production
▸ Roofing panels and trapezoidal roof sheets
▸ Winter garden and veranda systems
▸ Highway sound, wind, rain, and snow barrier systems
▸ Metro interior surface panels
▸ Bus stop panels and shelter structures
▸ Customized parking area applications
▸ Architectural glazing and insulation panels
Safety & Reliability
▸ Personnel protection sensor barriers
▸ Emergency stop systems
▸ CE, UL and CSA compliant
▸ 10-year spare parts and service guarantee
