Key Advantages
▸ Precision Control
Pneumatic thickness adjustment with automatic compensation and ±1°C cylinder tolerance.
▸ Thermal Stability
Double-walled cylinders and multi-zone cooling system ensure uniform temperature distribution.
▸ Compact & Flexible Use
100–300 mm width, 0.15–8 mm thickness range, optimized for laboratory-scale production.
▸ System Integration
- Extruder synchronization
- Industry 4.0 infrastructure
- remote access.
▸ User Experience & Safety
- User-friendly HMI
- Independent operation
- Sensor barriers
- Emergency stop
- Faster ROI & Long-Term Support
Technical Specifications
▸ Machine Width: 100 mm – 300 mm
▸ Thickness Range: 0.15 mm – 8 mm
▸ Thickness Control: Pneumatic
▸ Cylinder Structure: Double-walled, optimized flow design
▸ Temperature Tolerance: ±1°C
▸ Cooling System: 15-zone cooling system
▸ Measurement: Encoder-based precise length measurement
▸ Process Control System: PID-based SSR control
▸ Synchronization: Full line synchronization with extruder
Engineering & System Details
▸ Linear rail bearing system for stable and smooth operation
▸ Automatic thickness correction system
▸ Automatic tolerance adjustment
▸ Remote monitoring and control
▸ Multi-zone access and control system
▸ Laboratory-specific customized design
Application Areas
▸ Material testing and formulation trials
▸ R&D and laboratory-scale production
▸ Small batch sheet production
▸ Soft and rigid material testing
