Key Advantages
▸ Wide Speed Range
0.5 – 300 m/min adjustable speed.
▸ Controlled Pulling Force
Automatic pressure adjustment with stable grip.
▸ Product Protection
Special coated belts prevent slipping and deformation.
▸ Flexible Configuration
75–600 mm width, 600–2200 mm effective pressure length.
▸ User Experience & Reliability
User-friendly HMI, Faster ROI & Long-Term Support
Technical Specifications
▸ Speed Range: 0.5 – 300 m/min
▸ Working Width: 75 mm – 600 mm
▸ Effective Pressure Length: 600 mm – 2200 mm
▸ Drive Options: AC / Servo
▸ Pressure System: Automatic pressure adjustment
▸ Belt Structure: Special coated anti-slip belts
▸ Measurement: Encoder-based length control
▸ Synchronization: Full line synchronization with extruder
▸ Compliance: CE, UL, CSA
Engineering & System Details
▸ Optimized acceleration and deceleration control
▸ Stable pulling force distribution
▸ Protective covers and safety sensors
▸ High-efficiency operation support
▸ Process optimization based on customer requirements
▸ Remote monitoring and control
▸ Multi-zone access and control system
▸ 10-year spare parts availability and service guarantee
Application Areas
▸ Profile and pipe extrusion lines
▸ Sheet and strip applications
▸ Soft and rigid material processing
▸ Continuous extrusion production
