Key Advantages
▸ Performance
High output with stable and continuous production.
▸ Energy Efficiency
Up to 87% energy savings compared to conventional drive systems, achieved through optimized mechanical, thermodynamic, and friction design.
▸ Flexibility
Supports rigid–rigid, soft–soft, and rigid–soft material combinations.
▸ Technology
Industry 4.0 ready with full system synchronization.
▸ User Experience
User-friendly HMI with remote control access, Faster ROI & Long-Term Support
Technical Specifications
▸ Capacity: 50 – 1000 kg/h
▸ Main Extruder Diameter: Ø40 – Ø140 mm
▸ Co-Extruder Diameter: Ø25 – Ø65 mm
▸ Main Extruder L/D Ratio: 30
▸ Co-Extruder L/D Ratio: 26
▸ Material Compatibility: TPE, TPV, PVC, EVA, PC, PP, PE and more
▸ Heating Control System: PID with SSR
▸ Standards Compliance: CE, UL, CSA, Atex and Ex-Proof
Engineering & System Details
▸ Dynamic operating infrastructure
▸ Compact and space-saving design
▸ Suitable for laboratory-scale production
▸ Custom solutions based on customer requirements
▸ Full line synchronization
▸ Custom dosing systems
▸ Material-specific degassing system
▸ Remote control capability
▸ Multi-access regional control system
▸ 10-year spare parts and service guarantee
Application Areas
▸ Co-extrusion profile production
▸ Technical and industrial profiles
▸ Soft and rigid product applications
▸ Laboratory and R&D use
▸ Multi-layer extrusion solutions
