Key Advantages
▸ Continuous Precision Control
Motion control-based automatic adjustment with servo/hydraulic thickness control and ±1°C cylinder tolerance.
▸ Thermal Stability
Double-walled cylinders with optimized flow design for uniform heat distribution.
▸ Flexible Production Range
- 300–2400 mm width
- 0.07–18 mm thickness
- Multi-layer capability with edge control.
▸ Advanced Automation
- Fully automatic thickness control
- IO-supported programming
- Industry 4.0 integration
▸ User Experience & Safety
- User-friendly HMI
- Independent operation
- Sensor barriers
- Emergency stop
- Faster ROI & Long-Term Support
Technical Specifications
▸ Machine Width: 300 mm – 2400 mm
▸ Thickness Range: 0.07 mm – 18 mm
▸ Thickness Control: Servo / Hydraulic
▸ Process Control System: Motion control with IO-supported program
▸ Cylinder Structure: Double-walled, optimized flow design
▸ Temperature Tolerance: ±1°C
▸ Layer Options: Multi-layer compatible
▸ Measurement: Encoder-based precise length measurement
▸ Synchronization: Full line synchronization with extruder
Engineering & System Details
▸ Continuous automatic thickness adjustment (no interruption)
▸ Automatic tolerance alignment system
▸ Linear rail bearing system for high stability
▸ Edge control system for layer precision
▸ Remote monitoring and control
▸ Multi-zone access and control system
Application Areas
▸ High-precision sheet production
▸ Multi-layer sheet manufacturing
▸ PVC, PP, PE, PC processing
▸ Continuous industrial production lines
