Key Advantages
▸ High Precision Calibration
Up to 980 mbar vacuum with strong sealing.
▸ Energy Efficiency
Closed-loop system reduces energy consumption.
▸ Flexible Design Range
Custom sizes from 8 mm to 2100 mm.
▸ Advanced Motion Control
3-axis movement: manual, motorized, servo.
▸ User Experience & Reliability
User-friendly HMI, Faster ROI & Long-Term Support
Technical Specifications
▸ Product Range: 8 mm – 2100 mm
▸ Movement System: 3-axis (manual / motorized / servo)
▸ Vacuum Capacity: Up to 980 mbar
▸ System Structure: Fully stainless circulation system
▸ Pumps: Stainless vacuum and water pumps
▸ Control System: Industry 4.0 ready infrastructure
▸ Synchronization: Full line synchronization with extruder
▸ Compliance: CE, UL, CSA
Engineering & System Details
▸ Closed-loop water and vacuum system
▸ Jack-supported water and vacuum collectors
▸ Polycarbonate-specific heating & cooling system
▸ Blower-based water pushing system
▸ High sealing performance design
▸ Remote monitoring and control
▸ Multi-zone access and control system
▸ 10-year spare parts availability and service guarantee
Application Areas
▸ Profile extrusion lines
▸ Sheet and panel calibration processes
▸ PVC, PC, PP, PE applications
▸ Soft and rigid product production
