Key Advantages
▸ Precision & Thickness Control
Servo/hydraulic adjustment with automatic thickness compensation and ±1°C cylinder tolerance.
▸ Thermal Stability
Double-walled cylinders with optimized flow design for uniform heat distribution.
▸ Flexible Production Range
- 300–2400 mm width
- 0.07–18 mm thickness
- Multi-layer capability with edge control
▸ Integration & Control
- Extruder synchronization
- Industry 4.0 infrastructure
- Remote access.
▸ User Experience & Safety
- User-friendly HMI,
- Independent operation,
- Sensor barriers
- Emergency stop
- Faster ROI & Long-Term Support
Technical Specifications
▸ Machine Width: 300 mm – 2400 mm
▸ Thickness Range: 0.07 mm – 18 mm
▸ Thickness Control: Servo / Hydraulic
▸ Cylinder Structure: Double-walled, optimized flow design
▸ Temperature Tolerance: ±1°C
▸ Layer Options: Multi-layer compatible
▸ Process Control System: PID-based SSR control
▸ Synchronization: Extruder synchronized or standalone operation
Engineering & System Details
▸ Linear rail bearing system for high stability and smooth operation
▸ Automatic thickness correction system
▸ Automatic tolerance adjustment
▸ Edge control system for layer alignment
▸ Remote monitoring and control
▸ Multi-zone access and control system
Application Areas
▸ Sheet production lines (standalone or integrated)
▸ PC, PMMA, PS, PET, PETG, PP, PE
▸ Soft and rigid sheet applications
▸ Multi-layer sheet production
